A common IconFont package implemented in Swift to help you use IconFont in your project more conveniently, and integrates a series of free third-party icon libraries.

English Introduction

preview

Example

TestFlight

You can click below TestFlight button to download the sample program:

Compile the project manually

1. use git clone command to download this repository;
2. Use the cd command to switch to the warehouse directory and execute sh Startup.sh Order;
3. then open Example under the directory Example.xcworkspace Just compile.

or execute the following command:

git clone git@github.com:EFPrefix/EFIconFont.git; cd EFIconFont; sh Startup.sh; open Example/Example.xcworkspace;

need

Install

CocoaPods

EFIconFont can be obtained through CocoaPods.You only need to add the following code to your Podfile to import, the default only contains Core section, excluding font packs:

The integrated icon library resources of this library can be imported through subspecs. The following examples refer to AntDesign and FontAwesome resources:

pod 'EFIconFont', :subspecs => ['AntDesign', 'FontAwesome']

also via Complete Introduce all the icon library resources that have been integrated in this library, for example:

pod 'EFIconFont', :subspecs => ['Complete']

Then, execute the following command:

Swift Package Manager

The Swift Package Manager is a tool integrated into the Swift compiler for automating the distribution of Swift code.

If you’ve built your Swift package, it’s easy enough to add EFIconFont as a dependency, just add it to your Package.swift document dependencies item can be:

dependencies: [
    .package(url: "https://github.com/EFPrefix/EFIconFont.git", .upToNextMinor(from: "1.2.0"))
]

use

1. Core

accomplish EFIconFontProtocol An object of the protocol, capable of converting itself to NSAttributedString or UIImagethe content of the agreement is as follows:

public protocol EFIconFontProtocol {

    // `name` is not necessarily equal to .ttf file name
    var name: String { get }

    // `path` is path of .ttf file
    var path: String { get }

    // `attributes` is style of icon
    var attributes: [NSAttributedString.Key : Any] { set get }

    // `unicode` is unique identifier of particular icon
    var unicode: String { get }

    // `font` is UIFont of icon with input font size
    func font(size fontSize: CGFloat) -> UIFont?
}

• name: The font name, which is not necessarily equal to the .ttf file name. You can view its Name attribute acquisition;
• path: .ttf file path, generally through the form Bundle.main.path(forResource: name, ofType: "ttf") (if the file name and name are the same, you do not need to implement this property, just use the default implementation);
• attributes: the style of an icon (if there is no special requirement, the default implementation can be used);
• unicode: the unicode of a symbol;
• font: The font size of an icon corresponding to the input fontSize UIFont.

Objects that implement this protocol can be converted and output to strings and pictures by calling the following methods, and the foreground color and size can be changed:

// MARK:- String
func attributedString(size fontSize: CGFloat, attributes: [NSAttributedString.Key : Any]?) -> NSAttributedString?
func attributedString(size fontSize: CGFloat, foregroundColor: UIColor? = nil, backgroundColor: UIColor? = nil) -> NSAttributedString?

// MARK:- Image
func image(size fontSize: CGFloat, attributes: [NSAttributedString.Key : Any]?) -> UIImage?
func image(size fontSize: CGFloat, foregroundColor: UIColor? = nil, backgroundColor: UIColor? = nil) -> UIImage?
func image(size imageSize: CGSize, attributes: [NSAttributedString.Key : Any]?) -> UIImage?
func image(size imageSize: CGSize, foregroundColor: UIColor? = nil, backgroundColor: UIColor? = nil) -> UIImage?

2. Built-in icon library

This library has integrated AntDesign, FontAwesome and other free icon library resources. Students who need to use can import it. As shown below, you will get an EFIconFontProtocol Return value of type:

EFIconFontAntDesign.addteam

by following EFIconFontProtocol Protocol object acquisition NSAttributedString and UIImage:

EFIconFontAntDesign.addteam.attributedString(size: 24)
EFIconFontFontAwesomeBrands.adobe.attributedString(size: 32, foregroundColor: UIColor.white, backgroundColor: UIColor.green)
EFIconFontFontAwesomeRegular.addressBook.image(size: 24, foregroundColor: UIColor.red)
EFIconFontFontAwesomeSolid.alignLeft.image(size: CGSize(width: 36, height: 48), foregroundColor: UIColor.white)

All items of an icon library can be obtained in the following ways, and he will return [String : EFIconFontProtocol] Dictionary of type:

EFIconFont.antDesign.dictionary

Remarks: Although it is a free icon library, please ensure that your use method follows the usage agreement of the original author of the font library:

3. Custom Icon Library

(1) Import of font files

Convert the icon library we obtained in various ways .ttf file into the Xcode project and make sure Build Phases middle Copy Bundle Resources The font file is included in the list (by default it will be included when dragged into the project).

Also, this file is loaded on demand at runtime and does not need to be added to Info.plist in the file Fonts provided by application within the item.

(2) Implementation EFIconFontCaseIterableProtocol

The encapsulation of the icon library can be realized by implementing the EFIconFontCaseIterableProtocol protocol. In this project, Example demonstrates the customization method by taking the Octicons owned by GitHub as an example:

import EFIconFont

public extension EFIconFont {
    public static let octicons = EFIconFontOcticons.self
}

extension EFIconFontOcticons: EFIconFontCaseIterableProtocol {
    public static var name: String {
        return "octicons"
    }
    public var unicode: String {
        return self.rawValue
    }
}

public enum EFIconFontOcticons: String {
    case thumbsup = "\u{e6d7}"
    case unverified = "\u{e6d6}"
    case unfold = "\u{e6d5}"
    case verified = "\u{e6d4}"
    // ...
}

Some people want to ask how this huge enumeration was typed out by hand?Of course it’s generated by code… first put .svg Upload pictures to iconfont.cnthen look here.

(3) call

Ditto the use of the built-in icon library.

EFIconFontOcticons.thumbsup

(4) Precautions

The Octicons icon library in the example of this project is owned by GitHub, here is only a demonstration, please do not use it in any occasion that violates the specifications set by its owner:

4. Other

Crawling of some IconFont resource site materials and code generation methods:

author

EyreFree, eyrefree@eyrefree.org

protocol

EFIconFont is distributed and used under the MIT license, see the license file for more information.
